Model: HX-1080Y
Stamping Size: 200*800mm (W * Diameter)
Machine Speed: 600 - 800 cycles/hr
Machine Dimension: 2800*1250*1800mm
Machine Weight: 500kg
| Quantity: | |
|---|---|
HX-1080Y
HX
8443.39
Technical Parameter:
| Name | Hot Stamping Machine for Toilet Cover |
| Model | HX-1080Y |
| Control System | CAD NC Copying System with HMI |
| Stamping Head Driven | Servo Motor |
| Foil Driven | Servo Motor |
| Stamping Size | Diameter 800 * W 100 mm |
| Stamping Tempreature | RT ~ 250 |
| Max Stamping Speed | 600 - 800 pcs/hr |
| Power Supply | AC 110/220V 50/60HZ |
| Wattage | 5000W |
| Machine Dimension | L 2800 * W 1250 * H 1800 mm |
| Net Weight | 500 KG |
Technical Parameter:
| Name | Hot Stamping Machine for Toilet Cover |
| Model | HX-1080Y |
| Control System | CAD NC Copying System with HMI |
| Stamping Head Driven | Servo Motor |
| Foil Driven | Servo Motor |
| Stamping Size | Diameter 800 * W 100 mm |
| Stamping Tempreature | RT ~ 250 |
| Max Stamping Speed | 600 - 800 pcs/hr |
| Power Supply | AC 110/220V 50/60HZ |
| Wattage | 5000W |
| Machine Dimension | L 2800 * W 1250 * H 1800 mm |
| Net Weight | 500 KG |
