PTFE Tape Case Automatic Screen Printing Machine

Share to:
Model:HX-SLD1

Print Speed:1500 - 2000 cycles/hr

Print Diameter:64, 74, 86mm PTFE tape case

Machine Dimension:1850*1450*1700mm

Machine Weight:400 kg

Payment Terms:T/T, L/C, Paypal

Package:Exported Plywood

Availability:
Quantity:
  • HX-SLD1
  • HX
  • 8443.1921.90


PTFE Tape Case Automatic Screen Printing Machine


Technical Parameters:

Control System

PLC + HMI

Loading System

Automatic vibrating feeder

UN-loading System

Manipulator driven by cylinder

Drying System

UV curing

Conveyor System

Cam divider with gear motor

Electronic and pneumatic parts

SMC and MINDMAN

Workstations

12 pcs

Print Diameter

For 64, 74, 86mm PTFE tape

Machine Speed

1,500 ~ 2,000 pcs / hr

Power Supply

AC 220V, Single Phase

Air Supply

5 ~ 7 Bar


Functions:

1) . Adopt touch screen control panel, simple and convenient operation ;

2) . Auto 4-digit counter built in to count printing quantity;

3) . It’s special designed for printing Teflon tape cases ;

4) . In order to print different diameter Teflon tape case, the printing stroke and speed can be adjustable;

5) . The print-head can set up / down easily ;

6) . Controlling the speed of print squeegee and ink collect squeegee independently ;

7) . You can set screen frame by vertical, transverse or angle orientation ;

8) . Using high precision cam divider with gear motor to build up round worktable conveyor system ;

9) . UV drying system, can dry very fast ;

10) . Automatic loading by vibrating feeder ;

11) . Automatic UN-loading by manipulator ;

12) . Machine frame use coin alloy and metal coating surface ;


Machine Configuration:


Basic Structure

Machine frame

High quality square pass

Sealing plate

High quality cold rolling

Other metal parts

Cast aluminum and aluminum alloy

Transverse Driven System

Left/right driven

Motor

Guide

Linear guide

Scraper System

Scraper driven

Cylinder

Guide

Cross roller guide

Locating System

Precision Jig

Self made

Conveyor System

Cam Divider

Sun King

Control System

Control circuit

PLC with button

Pneumatic control

Airtac

Drying System

UV

De ke
